Similar Triangles and Area
Reference > Mathematics > Geometry > Similar TrianglesConsider the following diagram:
Suppose I told you that AB = 6, BC = 8, DE = 3, and EF = 4. Is that enough information to prove that the two triangles are similar?
It sure is! Because the Pythagorean Theorem shows us that AC = 10 and DF = 5, which gives us 3 pairs of sides that are in equal proportion.
So what is the ratio of a side of ABC to the corresponding side of DEF? The ratio is 2, because 6/3 = 8/4 = 10/5 = 2.
Now here's an interesting question: what is the ratio of the areas of those two triangles?
Well, if we remember that the area of a triangle is1/2bh, then we can easily find the two areas:
Area of ABC = 1/2(6)(8) = 24
Area of DEF = 1/2(3)(4) = 6.
Interesting; the ratio of the areas isn't 2 - it's 4! I wonder if we can find a pattern.
Suppose DE = 5, EF = 12, AB = 15, and BC = 36. These are still similar, because the hypotenuses of the triangles are 13 and 39, so the ratio of sides of ABC to corresponding sides of DEF is 3 (15/5 = 3)
What about the areas?
Well, the area of DEF is 30, and the area of ABC is 270.
What is the ratio of the areas here? It's 9.
This is interesting: when the ratio of the sides was 2, the ratio of the areas was 4, and when the ratio of the sides was 3, the ratio of the areas was 9. Does this look like a pattern?
22 = 4
32 = 9
It turns out that this pattern always works - if ratio of the sides of two similar triangles is x then the ratio of the areas of the triangles is x2
And they don't even have to be right triangles!
Example 1: Suppose ABC is similar to DEF, with AB = 5 and DE = 8. If the area of ABC is 50, what is the area of DEF?
Solution: The ratio of the sides is 5/8, so the ratio of the areas must be (5/8)2 or 25/64. So if the area of ABC = 50, then the area of DEF is 50(64/25) = 128.
Example 2: If XYZ is similar to JKL, and the area of XYZ is 4 times the area of JKL, then how many times the length of JK is XY?
Solution: The ratio of the areas is the square of the ratio of the sides, so if the ratio of the areas is 4, the ratio of the sides must be the square root of 4, or 2.
